cooking oil processing machine

Integrated sesame oil press machine with filter

Integrated sesame oil press machine with filter

Support to visit cooking oil processing machine factory, supply turn-key projects, provide customized services

Contact us:

sesame oil press machine
Integrated sesame oil press machine with filter

Integrated sesame oil press machine is an automatic combined oil expeller press with multi-use. Integrated sesame oil press machine is the new product developed by us according to the need of vegetable oil processing market. The integrated sesame oil presses has automatic function of hot press and cold press.

This series of integrated sesame oil press machine using the latest technology, high-quality steel, careful manufacture, convenient operation, vacuum filtration, high oil yield, oil is clean. It is suitable for crushing sesame, peanut, soybean, rapeseed, cottonseed, Tung seed, tea seed, perilla seed, sunflower seeds, castor seeds, almonds, walnuts and other oil crops, it also can be used for other oil plants cold and hot processing.

sesame oil press machine

Integrated sesame oil press machine

 5 Reasons to Choose Integrated Sesame Oil Press Machine With Filter
★   Wide application for various vegetable oil seeds such as peanuts, soybeans, sunflower seeds, sesame seeds, cottonseed, rapeseeds, palm kernels and so on.
★   Covering small space and easier to operate. Electric control cabinet makes the operating safer and easier. More efficient and labor-saving.
★   Continuous working with low noise.
★   High rate of oil yield with purer oil and good condition oil cakes. Vacuum filters in the machine help cleaning oils.
★   Be able to do both cold and hot pressing with automatic temperature rising and oil-cleaning system.

sesame oil
Sesame oil

Features of integrated sesame oil press machine with filter:
1.Advanced technology: reliable performance, simple operation, easy maintenance;
2.High oil yield: the optimized design, improve the oil yield;
3.Energy saving: adopt the new transmission device, improve the transmission efficiency;
4.Labor saving: with the labor supporting hoist and other auxiliary facilities, can save more human;
5.Wide use: It can be adapted to the majority of oil crops crush;
6.Pure oil: vacuum filtration residue, protect the oil clean;
7.Small footprint: integrated design, saving equipment operating space;

The commen oilseeds
Oil Extraction Rate:

Raw material Output Rate(%)  Thickness of Oil Cakes (mm) Oil Content of Dry Cakes (%)
Canola  30-38 1-1.5 ≤7.5-8
Cotton seed 12-14 1-2 ≤6.5-7.5
Soybean 10-16 2-2.5 ≤6.5-7
Peanut seeds 35-45 1-2 ≤7
Sesame 42-47 2-2.5 ≤6.5-7.5

Main Specifications of integrated sesame oil press machine:
We offer integrated sesame oil press machines with different models and capacities. Below are the technical data of each model.
Model Input Capacity(kg/h) Power(kw) Speed of screw
Weight(kg) Dimension L*W*H
DY-68A 40-60 5.5+1.5 137-160 450 1780×700×1320
DY-80A 80-100 5.5+1.5 80-100 700 1480×630×1570
DY-95A 150-180 7.5+1.5 33-39 950 2100×970×1970
DY-100A 150-180 7.5+1.5 36-39 1000 2250×890×1820
DY-105A 160-200 11+1.5 33-39 1200 2260×950×1800
DY-120A 200-250 15+1.5 32-39 1300 2280×890×1770
DY-130A 250-300 18.5+1.5 32-36 1500 2350×840×1850

1.The technical para. of the table refers to matching the cleaning, peeling, flaking, steaming and roasting accessories machinery, etc, steady operation, and adopts the hot pressing method to achieve the indicators.

2.the actual output may be slight different due to the difference of raw materials in terms of oil varieties, qualities and oil contents, as well as the working conditions.
3.Raw material feeding (kg/h) refers to the capacity after once hot press, and it would reduce to half of it if twice and one third if three times.

4.The machine meets the JB/T9793.1-1999 "agricultural screw oil press technology conditions", and Implement the national regulations of Warranty Services policy of P.R. China.
